Grundfos 22SQ15 220 SQ Series 3" Submersible Well Pump

Grundfos 22SQ15 220 SQ Series 3" Submersible Well Pump
$1,425.00 - $1,425.00
$1,425.00
$1,425.00 - $1,425.00
$1,425.00
✓ Authorized Grundfos Dealer
✓ Lowest Price Guaranteed
✓ Brand New & FREE Shipping: In Stock Ready To Ship
✓ Questions? Talk to a Grundfros Expert: 1-303-876-7654
✓ PRICE MATCH GUARANTEE


Renewable Outdoors LLC BBB Business Review

Login for Exclusive Member Pricing.
Not a member? Create a Free Account.

Grundfos 22SQ15 220 Well Pump

The Grundfos 22SQ15 220 Well Pump delivers strong, consistent water output with a compact design that’s ideal for residential wells and light commercial applications. This 1.5 HP submersible pump provides an impressive 22 GPM flow rate and is engineered to maintain reliable performance at depths up to 220 feet, making it a dependable solution for households that need steady pressure for everyday use.

Built with Grundfos’ proven SQ technology, the pump features soft-start capability to reduce electrical stress, protect components, and extend overall system life. Its lightweight, slim profile allows for easy installation into narrow well casings, while durable corrosion-resistant construction ensures long-term operation in challenging groundwater environments.

Designed for 240 VAC power systems, the 22SQ15 220 combines energy efficiency with exceptional pumping power, offering smooth, quiet performance and minimal maintenance requirements. It’s a strong choice for well owners who want reliability, efficiency, and long-lasting value in a high-quality submersible pump.


Grundfos 22SQ15 Specs & Features

  • Ideal for use with 3" I.D. or larger boreholes
  • Rated 15 GPM @ 250' Head Lift
  • 1-1/2 HP Permanent-Magnet (PM) Stainless Steel Motor (2-Wire - 200-240V)
  • Highly-efficient design with thermal overload protection for added safety
  • Fitted with a replaceable cable plug for ease of use
  • Soft Start Design allows for a low starting current with a smooth and steady acceleration
  • Dry-Running Protection helps extend pump life by preventing pump damage due to lack of water in well
  • Polyamide reinforced hydraulic pump components for more efficient energy use
  • "Floating" Impellers w/ Tungsten Carbine/Ceramic Bearings
  • Top-Bearing Upthrust Protection provides added protection to motor/pump during start-up
  • Overvoltage & Undervoltage Protection
  • Overtemperature Protection
  • Voltage: 240 Volt
  • Running Amps: 12.3
  • Wire: 2-Wire
  • Thermal Protection: Yes
  • Gallons Per Minute: 22 Gallons
  • Outlet Diameter: 1-1/2 Inch
  • Self Priming: Yes
  • Total Head Lift: 348Feet
  • Discharge Port Size: 1-1/2 Inch
  • Horsepower: 1 HP
  • Weight: 16 Pounds
  • Dimensions (LxWxH): 38.2" x 2.9" x 2.9"


Your Satisfaction with Grundfos is Guaranteed:

  • 2-Year Limited Warranty
  • Lowest Price Guarantee
